XAL6060-103MEC

Coilcraft

FIXED IND 10UH 7A 29.82MOHM SM

XAL6060-103MEC Datasheet

$

Bulk RFQ

Bulk BID

Products specifications

Attribute name	Attribute value
Package	Tape & Reel (TR)
Product Status	Active
Type	Molded
Material - Core	Metal Composite
Inductance	10 µH
Tolerance	±20%
Current Rating (Amps)	7 A
Current - Saturation (Isat)	7.6A
Shielding	Shielded
DC Resistance (DCR)	29.82mOhm Max
Q @ Freq	-
Frequency - Self Resonant	14MHz
Ratings	AEC-Q200
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	1 MHz
Features	-
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.258" L x 0.250" W (6.56mm x 6.36mm)
Height - Seated (Max)	0.240\
